| SCALE-2 Driver Cores | |||
| Device Part No. | Channels | Gate Power Driver Current per channel |
IGBT Blackdown Voltage |
|---|---|---|---|
| 2SC0106T | 2 ch | 1W +/-6A |
1200V |
| 2SC0115T2A0-12 and 2SC0115T2A0C-12 | |||
| 2SC0115T | 2 ch | 1W +/-15A |
1200V |
| 2SC0115T2A0-12 and 2SC0115T2A0C-12 | |||
| 2SC0108T | 2 ch | 1W +/-8A |
1700V |
| 2SC0108T2D0-07 Preliminary Data Sheet | |||
| 2SC0435T | 2 ch | 4W +/-35A |
1700V |
| 2SC0435T2F1-17 and 2SC0435T2F1C-17 | |||
| 2SD300C17 | 2 ch | 4W +/-30A |
1700V |
| 2SD300C17A1 and 2SD300C17A1C | |||
| 2SC0650P | 2 ch | 4W +/-50A |
1700V |
| 2SC0650P2Ax-17 | |||
| 1SC2060P | 2 ch | 1W +/-60A |
1700V |
| 1SC2060P2Ax-17 | |||
| SCALE-2 Driver Cores | |||
| Device Part No. | Channels | Gate Power Driver Current per channel |
IGBT Blackdown Voltage |
|---|---|---|---|
| 2SC0535T | 2 ch | 5W +/-35A |
3300V |
| 2SC0535T2A1-33 and 2SC0535T2A1C-33 | |||
| 2SC0635T | 2 ch | 6W +/-35A |
4500V |
| 1SC0450V2 1SC0450E2 |
2 ch | 6W +/-50A |
6500V |
| 1SC0450E2A0-45 and 1SC0450E2A0-65 | |||
